Commercial series

The first true reversible system for the heating and cooling of pool water in North America. This product line was introduced in 2007 and has an awesome reliability record. This product won the award of the best new product of its class in 2008. Its zinc plated steel case, covered with baked paint makes a good looking and durable product.

Designed for large loads like olympic pools, wave pools and other large pools, the commercial line has no capacity limit. The units can even be controlled remotely to make your operations easier.

A light commercial line is also available. These units have a capacity of up to 300 000 BTU/hr (87.9 kW) and are perfect for luxury apartment buildings, inns and small hotels that do not have three phase power supply.

 Split system
 Combined system
 Reversible systems principle
 Energy savings
 Energy comparison
 Grants
 Manufacturing quality
 Technical informations
 Frequently asked questions


Light commercial series (triple-phase power supply*)

Technical specifications

Model BTU/hr Dimensions
(D x W x H)
Voltage Amps db(A)
PASRW130_U_1 POPASRW100S-U 170 000 57 x 29 x 42 208-230/1/60 ± # 39.1 61
POPASRW130S-U 200 000 57 x 29 x 52 208-230/1/60 ± # 45.2 61

*Single phase version also available.


Commercial series

Technical specifications

Model BTU/hr Dimensions
(D x W x H)
Voltage Amps db(A)
PASRW250S_U_1 POPASRW250S-U 306 000 80¾ x 35½ x 75½ 400-460/3/60 ± 26.1 62
PASRW400S_U_1 POPASRW400S-U 476 000 857/8 x 43¼ x 82¾ 400-460/3/60 ± 40.5 65
PASRW450S_U_1 POPASRW500S-U 683 000 87¾ x 42¼ x 81¼ 440-460/3/60 ± 63 85

Comfort and energy efficiency
